High Accuracy Video Measuring System Measuring Machine

FOB Reference Price:Get Latest Price
$65,000.00 - $80,000.00 / Pieces | 1 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 30 Negotiable
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Jaten, JATEN
Model Number:
MV2616
Certificate:
CE ISO
Power supply:
220V10%,50Hz
Grating ruler:
America GSI(resolution:0.5m)
CCD:
Japan STC 625
Product name:
Industrial Testing Machine
Standard:
ISO9001:2008
Warranty:
1 Year
Function:
precision testing
Color:
Grey+blue
Supply Ability
Supply Ability:
10 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
vacuum packing& free fumigation wooden case
Port
shenzhen
Lead Time :
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Product Description
High quality video measuring system

Video Measuring System Measuring Machine




Features:

 It used in Japan 1 / 2 color CCD camera, zoom lens and the cross-line generator as a measure aiming system .

Digital measurement and data processing system consists of two coordinates studio, optical grating and the composition of DC-3000 electric box.

Optical Coordinate Measuring Machine has a variety of data processing, display, input, output, in particular, is very useful function of the workpiece straighten .

It has R232 interface with a computer and specialized measurement software which can also be processed and output circular mapping.

The base and columns are marble from the overall composition.

Product Detail

Jaten MV series large travel gantry CNC video measuring machine

Model

MV-6060CNC

MV-6080CNC

MV-7070CNC

WORKING STAGE

X,Y,Z-axis Travel(mm)

600x600x200

600x800x200

700x700x200

dimensions (mm)





1750*1510*1700

Load-bearing weight(KG)





30

net Weight(KG)





1960

Model

MV-1080CNC

MV-1210CNC

MV-1612CNC

WORKING STAGE

X,Y,Z-axis Travel(mm)

1000*800*200

1200*1000*200

1600*1200*200

dimensions (mm)

2050*1610*1700

2200*1810*1700

2600*2010*1700

Model

MV-1812CNC

MV-2216CNC

MV-2616CNC

WORKING STAGE

X,Y,Z-axis Travel(mm)

1800*1200*200

2200*1600*250

2600*1600*200

dimensions (mm)

2800*2010*1700

3200*2410*1850

3600*2410*1850

Accuracy

X,Y-axis (um)

≤(3+L/200)um, Repeatability 2um

Z-axis

≤(4+L/200)um

Grating ruler

High-precision grating ruler, resolution 0.5um

CCD

Japan Sentech Color 625 colorful CCD Camera

Optical system

Automatic Zoom Lens ,Object View:7~1.1mm, zoom ratio 12X, Video Total Magnification:30X~230X ,

Optional Laser,UK Renishaw Probe ,can measure the thickness of transparent glass and flatness

illumination system

Continuous adjustable LED ring surface &contours&coaxial light, according to program-controlled to adjust the intensity&rate of light

Software system

QuickMeasuring,Automatic video measurement software

working environment

20°C±3°C, Temperature 45% -75%, isolated from the external vibration source

power supply

220V±10%,180V~260V(AC),50HZ

Optional Accessories

Can match with Objective/Laser/Probe/cupboard/version/ Brand CCD......

Applicable objects:

The perfect vision system for non-contact measurement and further inspection of Stamped and injected parts,Plastic parts, injection moulds,Electronic and other components commonly used in silk screen printing as well as the lead industry among others.



automatic electronica video measuring system With Good Quality

Main Function
1. Double closed-loop motion control, embedded modules developed to control motor with precise positioning performance.
2.Surface light formed by 24 groups independent light source , each group are constant current source driver and 200-step continuous variable.
3.Optical measurement system can measure point, line, circle, arc and oval, rectangular with the multi-point positioning function,combination of measurements, center structure and the intersection of structure, the midpoint of construction, line structure, a round structure.
4. High Accuracy CNC optical measurement machine has various functions of data processing, display, input and output, Measurement data output Word,Excel and AutoCAD directly to conduct statistical analysis,particularly, the work piece straightening function is very useful.
5. Macros will be faster and more convenient to measure the same spare parts, for the improvement of measurement efficiency.

Company Information

Company profile



Dongguan Jaten Instrument Co.,Ltd . It was founded in 2005, is a specialized in dimensional measuring instrument precision optical testing instruments and automatic dispensing machine, electronic product dispensing machines, multi-axis dispensing machine, PCB dispensing machines .



Related Products-2



          Optical Profile Projector                              Toolmaker Microscope                  Glue Dispensing Machine



Packaging & Shipping

<< Professional packaging:

1pc with poly bag.wooden case and canton box are available. make sure the machine safe.
Shipping :2 working days after order confirmed.

<< Trade information
Trade Terms: FOB,CIF,EXW

Payment Terms: T/T ,Western Union,Paypal,Escrow.MoneyGram.
Payment Condition: 30% deposit in advance,70% balance before delivery. payment terms can be discussed.
Delivery Time: 5-7 working days after receive the deposit.
Packing: Wooden case .Professional export standard packaging to protect the goods.
Shipping : By sea,By air and by express delivery.

Our Services

1. 12 Months warranty for the mother board and glue dispensing machie
2. Life-long maintenance service for the product

FAQ



Equipment Service:

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.



Onsite Service:

1.Device installation; 2.Equipment Operation Test Technology training;3.Equipment Calibration;4.Daily maintenance and maintenance of equipment



Free technical training for visiting factories



24-hour Online contact



Free software upgrades



Free information:

1.Product Instruction;2.Product operation instruction/video;3.Experiment Test (test application, test report)



Device Problem Handling:

1. Social media 24 hours online communication;2. Mail Seamless Docking;3. Video Conferencing;4. Artificial free door-to-door service
